Gripper Lite

Gripper Lite

Designed for Small, light, consistently shaped objects in light-duty and education setups.

Key Specifications

16 mm
Stroke
1 kg
Max payload
5 N
Gripping force
GOOD TO KNOW

Lead time: 2–4 weeks

Certifications: CE

Warranty: Every unit comes with a 1-year warranty and lifetime technical support.

Payment: We accept PayPal at checkout. For alternative payment methods, email us at sales@ufactory.cc.

Trade terms: All orders ship EXW. Import duties, taxes, and customs clearance are the buyer's responsibility.
$360.00

Compatible Cobots

UFACTORY Lite 6

UFACTORY Lite 6

UFACTORY Lite 6
$2,999.00

Key Features

1
Compact and Lightweight
Weighing only 350 g, the gripper mounts easily on the UFACTORY Lite 6.
2
Replaceable Fingers
Interchangeable fingers support different object shapes and a range of basic handling tasks.
3
Simple Digital I/O Control
Straightforward open-and-close control enables quick integration with automation systems.
4
Low Power Consumption
Operates on a 24 VDC supply with static power consumption as low as 0.5 W.
5
Reliable Light-Duty Gripping
A 16 mm stroke and 5 N gripping force provide dependable handling for small and lightweight objects.

UFACTORY 2-Finger Grippers Comparison

Gripper UFACTORY Gripper LiteGripper Lite UFACTORY Gripper G2Gripper G2 UFACTORY BIO Gripper G2BIO Gripper G2
Cobot compatibilityLite 6xArm Series, 850xArm Series, 850
Best forSmall, light, consistently shaped objectsFirm, consistently shaped objectsFlat, delicate items such as 96-well plates
Supply voltage24 VDC, 500 mA max.24 VDC, 1.5 A max.24 VDC, 1.5 A max.
Max supply voltage26 VDC28 VDC28 VDC
Static power0.5 W1 W0.72 W
Weight350 g800 g790 g (with adapter)
Payload≤ 1 kg≤ 5 kg≤ 5 kg
Stroke / range16 mm84 ± 1 mm71–150 mm
Finger typeReplaceableReplaceableReplaceable
Gripping force5 N10 to 50 N20 N
CommunicationDigital I/ORS-485, Modbus RTURS-485, Modbus RTU
Programmable parametersN/ASpeed 15–225 mm/s, position 0–840 mm, force 1–100%Speed 0–4,000 rpm, position 71–150 mm, force 1–100%
Status indicatorN/AN/AWorking, power
FeedbackN/APosition/pick/releasePosition/pick/release
Lifespan>6,000 h>2,000,000 cycles>30,000 h
Operating environment0 to 50 °C, IP400 to 50 °C, IP400 to 50 °C, IP40
